STAX SRM-400S: High-End Semiconductor Amplifier for Audiophiles
The STAX SRM-400S is an advanced, fully semiconductor-based driver unit specifically designed for discerning audiophiles. This amplifier sets new standards in sound reproduction with its custom low-noise dual FETs in the first amplification stage and, for the first time in STAX's history, a J-FET in the second stage.
The use of a J-FET, renowned for its superior performance in low-noise amplification, ensures excellent high-frequency response and a clear, detailed sound signature. The large current emitter follower circuit fully unleashes the potential of the ear speakers, making it capable of driving music sources with high-frequency content effortlessly.
The SRM-400S is engineered to reproduce musical details precisely and authentically, providing an unparalleled listening experience for those who demand the highest quality sound.
Technical Specifications of the STAX SRM-400S
- Type: Fully configured FET-DC amplifier module
- Frequency Response: DC - 100 kHz (with an SR-009S)
- Gain: 60 dB
- Harmonic Distortion: 0.01% or less (at 1 kHz/100 Vrms output)
- Input Impedance: 50 kΩ (RCA), 50 kΩ x 2 (XLR)
- Maximum Output Voltage: 450 Vrms (at 1 kHz)
- Bias Voltage: PRO 580 V
- Operating Temperature/Humidity: 0 to 35 °C / less than 90% (non-condensing)
- Input Connections: RCA x 1, XLR x 1
- Output: RCA parallel output
- Power Consumption: 46 W
- Dimensions: 240 mm (W) x 103 mm (H) x 393 mm (D) (including maximum protruding parts)
- Weight: 6.3 kg
The SRM-400S is an exceptional choice for audiophiles seeking detailed, precise sound reproduction in a robust and modern design, delivering the quality that STAX is known for.
